本機用于各種等級的原棉、化纖的喂入和計量，每條生產線一般配備二至三臺，滿足二至三種纖維的混合。
纖維由人工開包，平簾輸入，斜簾抓取，電子秤按不同的配比自動秤量，使不同的原料精確稱重混合，保障非織造布成品的工藝要求。
This machine is used for feeding and measuring various grades cotton wool and chemical fiber. It general each production line is equipped with 2 to 3 sets of electronic balance that can meet the mixing of 2 to 3 varieties fibers.
The fiber is opened manual and put by even curtain and grasped by incline curtain. The electronic balance can weigh automatically in accordance with different mixture ratio and make different raw materials weigh and mix exactly and guarantee technological requirement of non—woven cloth nni shed product.
一．主要技術參數：Main technical parameters
1. 幅寬Width：1000mm~1200mm
2. 產量Output：100kg/h~150kg/h
3. 功率Power：4.5KW
二．結構描述：Description of structure
1. 打手Beater：￠355mm
2. 斜簾Incline curtain：pvc開口皮簾子+梳針角釘 pvc opening rubber curtain +comb needle brad
3. 平簾Even curtain：pvc皮簾子 pvc curtain
4. 采用大速比擺線針輪減速機傳動平簾，采用變頻減速機傳動斜簾
The use of large ratio cycloid reducer transmission level screens, the use of variable frequency drive reducer inclined screens. |
