強力加壓翻轉式密煉機...
|
| 強力加壓翻轉式密煉機 |
|
| 產品名稱：強力加壓翻轉式密煉機 |
| 產品編號：— |
發布日期：
2014/1/14 |
| 產品產地：— |
產品規格：可根據用戶需求定制 |
| 產品商標：— |
 |
|
|
|
|
|
 輕量化高效節能環保型現代化煉膠、煉塑設備
Light-weight high-efficiency and energy saving type modern
device for mixing rubber and plasti
用途：橡膠、塑膠及化工原料混合密煉加工
Applied to Rubber plastic & Chemical Industry
翻轉式密煉機規格
Specifications For Dispersion Kneader
| 型號ModeL |
X(S)N—5 |
X(S)N—10 |
X(S)N—20 |
X(S)N—3S |
X(S)N—55 |
X(S)N—75 |
X(S)N—110 |
X(S)N—150 |
X(S)N—200 |
密煉容量
Mixing Capacity |
L |
5 |
10 |
20 |
35 |
55 |
75 |
110 |
150 |
200200 |
驅動電機
Main Power |
KW |
7.5 |
15 |
30 |
55 |
55／75 |
90／110 |
160／200 |
220 |
280 |
翻轉電機
Brake Motor |
KW |
0.55 |
0.75 |
1.5 |
2.2 |
3.0 |
4.0 |
5.5 |
55 |
7.5 |
翻轉角度
Tilting Angle |
|
110 |
110 |
110 |
140 |
140 |
140 |
140 |
140 |
140 |
空壓機
Air Compressor |
kw |
1.5 |
2.2 |
3.0 |
5.5 |
5.5 |
7.5 |
7.5 |
15 |
20 |
集塵器
Dust Collector |
|
HLL—10 |
HLL—10 |
HLL—10 |
HLL—10 |
HLL—15 |
HLL-20 |
HLL-30 |
HLL-30 |
HLL-30 |
水冷卻（煉膠）
Coolin9 Water (mixing rubber) |
Mpa |
O.2-O.4 |
0.2—O.4 |
O.2—O.4 |
O.3—O.4 |
O.3—O.4 |
O.3—O.4 |
O.3—O.4 |
O.3—O.4 |
O.3—O.4 |
汽加熱（煉塑）
Hea ng Steam (mixing plastics) |
Mpa |
O.5—O.8 |
O.5—O.8 |
O.5—O.8 |
O.5—0.8 |
O.5—O.8 |
O.5—O 8 |
O.5—O.8 |
O.5—O.8 |
O.5—O.9 |
電加熱（煉塑）
Electdc Heater (mixing plastics) |
Mpa |
4 |
6 |
9 |
12 |
15 |
18 |
24 |
28 |
32 |
機器重量
Machine Weight |
kg |
1200 |
2300 |
4500 |
6500 |
7800 |
10500 |
14500 |
19500 |
22500 |
外型尺寸（長×寬×高）
Overall Dimensions (L ×W ×H) |
mm |
1900 ×1000 ×200 |
2200× 1350×2150 |
2500 ×1480 ×2500 |
3200× 1900
×3000 |
5300×2000
×3100 |
3800×2380
×3200 |
4100× 2700×3580 |
4200×3300
×3900 |
4560× 3400
×4200 | | |
| |
| |
|
|
|
|
|
|
|
|
|
